System Interface
|
Data transfer speed
|
Max. 150 MB/s
|
Performance
|
|
|
CD
|
|
Key: insert "Max X" speed for each media below. For CD 1X=150 KB/s; DVD
1X=1350 KB/s; BD 1x = 4.5 MB/s
|
|
Read
|
Max.24X
|
|
Digital Audio Extraction (DAE)
|
Max.20X
|
|
Write CD-R
|
Max.24X
|
|
Write CD-RW
|
Max.16X
|
DVD
|
|
|
|
Read (Single Layer / Dual or Double Layer)
|
Max. 8X/6X
|
|
Write DVD+/-R |
Max.8X |
|
Write DVD+R Double Layer
|
Max.4X
|
|
Write DVD-RAM
|
Max.5X
|
|
Write DVD+RW
|
Max.8X
|
|
Write DVD-RW
|
Max.6X
|
BD |
|
|
|
Read BD-ROM |
Max. 6X |
|
Write BD-R |
Max. 6X/4X
|
|
Write BD-RE |
Max. 2X/2X
|
Power Consumption
|
Typical
|
1100 mA
|
Acoustic noise
|
Operating (Sound pressure level, typical)
|
less than 50 dBA
|
Power supply
|
Voltage
|
DC5V +/-0.25V
|
Temperature
|
Operating C
(F)
|
5 °C ~ 50 °C (41 °F ~ 122 °F)
|
|
Non-operating C (F)
|
-40 °C ~ 65 °C (-40 °F ~ 149 °F)
|
Relative Humidity
|
Operating (No condensation)
|
10 % ~ 90 %
|
|
Non-operating (No condensation, Power Off, without disc)
|
5 % ~ 95 %
|
Altitude
|
Operating m (ft)
|
-200 m ~ 3,048 m (-656 ~ 10000 ft)
|
|
MTBF:
|
60,000 h (Duty:20 %)
|
Dimensions and weight
|
|
|
|
Width mm (in)
|
128 mm (5.04 in)
|
|
Depth mm (in)
|
127.0 mm (5.00 in) except bezel
|
|
Height mm (in)
|
12.7 mm (0.5 in)
|
|
Weight g
|
185 g +/-10 g |
