Based spec
|
Interface
|
2.5” IDE 44PIN
|
Dimension
|
100*70*9.5 mm
|
Weight
|
62~72 g
|
Capacity
|
8GB~128GB
|
Flash type
|
MLC NAND Flash
|
Read/Write Performance
|
Sequential Read
|
Up to 95MB/S
|
Sequential Write
|
Up to 90MB/S
|
4KB Random Read IOPS
|
3200
|
4KB Random Write IOPS
|
300
|
Response Time
|
0.2ms
|
Power Consumption
|
Power Supply
|
5V+5%
|
Standby
|
0.3W
|
4KB Random Write
|
2W
|
Reliability
|
Write endurance: 8 years @ 100G write/day(32G)
|
Read endurance: unlimited
|
MTBF: >2,000,000 hours
|
Data retention: >20years @ 25°C
|
Data destroy do not support
|
Sudden power-off recovery support
|
ECC: 8bits or 15bits for 512Bytes
|
S.M.A.R.T and dynamic power management support
|
Static and dynamic wear-leveling
|
Bad block management algorithm
|
Environment
|
Storage temperature: -55~95°C
|
Operation temperature: 0~70°C
|
Humidity: 5%~95%
|
Vibration: 20G Peak, 10 ~ 2000Hz, (15mins/ Axis) x3 Axis
|
Shock: 1500G (@0.5ms half sine wave)
|
